1.Powerful strength, which is suitable to all environments.
2.Three forward speed and two backward changes. Reinforced plastic spraying box and multi-layer water filter ensure the stability of the system.
3.With stepless speed changes is easy and reliable to operate.
4.Power strength, which adopted 4BT Cummins engine, is suitable to all environments.
| Model | SCP2030 | SCP1826 | SCP1016 | SCP2030H | SCP1826H | SCP1016H | |
| Operaing mass | Kg | 20000/30000 | 18000/26000 | 10000/16000 | 20000/30000 | 18000/26000 | 10000/16000 |
| Max travel speed | km/h | 20.64 | 20.64 | 14.7 | 10 | 10 | 14 |
| Tyre quantity(Front+Back) | 5+6 | 5+6 | 4+5 | 5+6 | 5+6 | 4+5 | |
| Min.turning radius | mm | 8000 | 8000 | 7500 | 8000 | 8000 | 7500 |
| The presses the width | mm | 2790 | 2790 | 2280 | 2790 | 2790 | 2280 |
| Grade ability | % | 30 | 30 | 30 | 30 | 30 | 30 |
| Overall dimension | mm | 4950×2750×3240 | 4950×2750×3240 | 4780×2100×3200 | 4950×2750×3240 | 4950×2750×3240 | 4780×2100×3200 |
| Wheelbase | mm | 3800 | 3800 | 3700 | 3800 | 3800 | 3700 |
| Diesel power | kW | 125 | 125 | 75 | 125 | 125 | 75 |
| Dieselmode | 6BTA5.9 | 6BTA5.9 | 4BT3.9 | 6BTA5.9 | 6BTA5.9 | 4BT3.9 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
