Secsun Machinery

Bulldozer

220 HP Crawler Bulldozer


Horsepower:220 HP

Blade Width:3725 mm

Rated Power:175/1850 kw/rpm

Engine Model:CUMMINS NT855-C280S10
Description Warranty Info
Description

1.Features a wide and durable blade that can effectively push, grade, and level various types of materials, including soil, gravel, and debris.

2.Compatible with various attachments, such as ripper blades, winches, and scrapers, allowing for increased functionality and adaptability to different job requirements.

3.Utilizes a heavy-duty track system for enhanced stability and traction on uneven terrain, minimizing ground pressure and preventing damage to soft surfaces.


Model
SBD220
TypeHP220
Engine
CUMMINS NT855-C280S10
DisplacementL14.01
Rated power(kw/rpm)kw/rpm175/1800
Max.torqueN.m/rpm1030/1250
Operating weightT23.5
Dimension(no ripper)mm5460×3725×3395
Grounding lengthmm2730
Ground pressureMPa0.077
Track gaugemm2000
Dozing capacity6.4
Blade widthmm3725
Blade heightmm1317
Max drop below groundmm540
Track shoe widthmm560
Pitchmm216
Quantity of track link
38
Quantity of Carrier rollers
4
Quantity of Track rollers
12
Max pressureMPa14
DischargeL/min262
Max tractor forceKN202
Grade ability°30°
Forward SpeedKm/hF1:0-3.6
F2:0-6.5
F3:0-11.2
Rear SpeedKm/hR1:0-4.3
R2:0-7.7
R3:0-13.2


With technological innovation, our product configuration and parameters will continue to change without notice;

if there is any doubt, the specific confirmation of our international trade sales shall prevail.

Warranty Info

Warranty Term

1. One year or 2000 working hours which occurs first.

2. 24 hours On-line service
