1.Features a wide and durable blade that can effectively push, grade, and level various types of materials, including soil, gravel, and debris.
2.Compatible with various attachments, such as ripper blades, winches, and scrapers, allowing for increased functionality and adaptability to different job requirements.
3.Utilizes a heavy-duty track system for enhanced stability and traction on uneven terrain, minimizing ground pressure and preventing damage to soft surfaces.
| Model | SBD240 | |
| Type | HP | 240 |
| Engine | CUMMINS NTA855-C280 | |
| Displacement | L | 14.01 |
| Rated power（kw/rpm） | kw/rpm | 187/1850 |
| Max.torque | N.m/rpm | |
| Operating weight | T | 23.5 |
| Dimension(no ripper) | mm | 5390×3735×3350 |
| Grounding length | mm | 2730 |
| Ground pressure | MPa | 0.077 |
| Track gauge | mm | 2000 |
| Dozing capacity | m³ | 6.4 |
| Blade width | mm | 3735 |
| Blade height | mm | 1310 |
| Max drop below ground | mm | 540 |
| Track shoe width | mm | 560 |
| Pitch | mm | 216 |
| Quantity of track link | 38 | |
| Quantity of Carrier rollers | 4 | |
| Quantity of Track rollers | 12 | |
| Max pressure | MPa | 14 |
| Discharge | L/min | |
| Max tractor force | KN | 203 |
| Grade ability | ° | 30° |
| Forward Speed | Km/h | F1:0-3.6 |
| F2:0-6.5 | ||
| F3:0-11.2 | ||
| Rear Speed | Km/h | R1:0-4.3 |
| R2:0-7.7 | ||
| R3:0-13.2 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
