1.The throttle follower control provided to control engine speed, one-hand joystick and proportional electric control allow flexible, precise and efficient control.
2.Higher lift speed and faster dynamic response effectively improve operating efficiency.
3.Maintenance-friendly design: a wide-opening hood, large-space electric control box, larger cab space.
4.Multiple hydraulic inspection points, easy access to oil and water during inspection, and integrated intelligent instrument diagnostic and query functions.
| Model | SCRS4531E | ||
| length | mm | 11340 | |
| Width | Spreader | mm | 6053 |
| Front wheel | mm | 4200 | |
| Height | mm | 4670 | |
| Wheelbase | mm | 6000 | |
| Trace | Front | mm | 3033 |
| Rear | mm | 2790 | |
| Overhang | Front | mm | 840 |
| Rear | mm | 1194 | |
| Min. ground clearance | mm | 350 | |
| Min. turning radius | mm | 8000 | |
| Max. gradeability | % | 13% | |
| Dead weight | kg | 71200 | |
| Rated lifting capacity | kg | 45000 | |
| Stacking capacity | —— | 2005/5/4 | |
| Max. lifting height | mm | 15100 | |
| Max. lifting speed | Unloaded | mm/s | 420 |
| Rated load | mm/s | 250 | |
| Max. lowering speed | Unloaded | mm/s | 360 |
| Rated load | mm/s | 300 | |
| Max. traveling speed | Unloaded | km/h | 20 |
| Rated load | km/h | 14 | |
| Aisle width | 20’ | mm | 11300 |
| 40’ | mm | 13600 | |
| Voltage of battery pack | V | 618 | |
| Capacity of battery pack | km/h | 422 | |
| Motor peak power | kw | 346 | |
| Motor peak torque | Nm | 3800 | |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail.
Warranty Term
1. One year or 2000 working hours which occurs first.
2. 24 hours On-line service
